SOLID WOVEN COTTON, KEVLAR & POLYESTER CONVEYOR BELTING

---

100% Solid woven cotton conveyor belting is a product that has survived the test of time. This versatile product can be found in food processing, corrugated box manufacturing, packaging, and more. Traditionally manufactured in 1, 2, 3, and 4 plies and up to 50 inches wide. Supplied in full rolls, cut pieces, sewn endless, laced, cut and overcast, grommets, or with cleats.

Upson Maybach Stock Woven Cotton Widths:

1 Ply Cotton: 39, 40, 50 inches

2 Ply Cotton: 4, 8, 12, 40, 42 inches

4 Ply Cotton: 4, 6, 12, 18, 24, 36, 48 inches

Custom widths available upon request!

Upson Maybach's solid woven Kevlar belting is 100% Virgin Dupont Kevlar.  A high temperature and extremely durable material, solid woven Kevlar belts are used for the most challenging and hot applications - up to 950 degrees F. This belting is also available with anti static black PAN fibers or steel cords woven throughout.

Supplied in full rolls, cut pieces, sewn endless, laced, cut and overcast, grommets, or with cleats.

4 plies of Kevlar is the industry standard for belting material.

Upson Maybach Stock Woven Kevlar Widths:

4 Ply Kevlar: 1.13, 1.5, 1.75, 3, 4, 4.94, 6, 12, 18, 24, 36 inches wide.

Custom widths available upon request!

Historically high temperature belting was woven but the weave pattern was undesirable in some industries, like aluminum extrusion, where the belting weave could transfer onto the aluminum profile.  Needled belting of Kevlar, Nomex, and Polyester has now been a market standard for years in the aluminum extrusion industries.  The same advantages of high temperature Kevlar, but needled for a smoother finish. These belts are made to order and can be supplied as pads, truly endless belts, truly endless roller coverings, or as backings on timing belts.

Two ply polyester belts are a common specification on microwave pasteurization ovens and post-baking dryers.  Common OEMs in this field are Strayfield and Radio Frequency Co.  Upson Maybach's replacement microwave belts hold up abrasive products like baked salted snacks or heavy loads like bulk flour.

Air Slide belts are used in low pressure, enclosed conveyors where air is forced through the belt causing a bulk power, such as cement, to fluidize. Air blown through the belt transports the bulk powder along the length of the belt. Air slide belts are made to order and are cut to your desired width and length. Air slide belts are heat treated and will have heat sealed edges to ensure no edge fraying.

We fabricate Cotton, Kevlar, and Polyester belting in house!  We have multiple industrial sewing machines ready to turn your concept into a belt.  We offer the following fabrication services:

Flexco Lacing, Viton treated ends, sewn cover flaps, sewn endless, sewn plastic spiral lacing, cleats, grommets, custom width cut and overcast, mineral oil treatment, and more. Call the shop to discuss your fabricated woven belting applications!

Upson Maybach fabricates Flux Belts for Automatic Girth Welders (AGW) and Automatic Tank Welders (ATW)!  Flux Belts are special, abrasion and temperature resistant belts designed to transport Flux during the welding of horizontal seams for oil, gas, and grain storage tanks.

Upson Maybach Flux Belts hold the flux at the weld joint to help make strong welds and reduce Flux waste. Our Flux Belts are continuous belts made in an endless loop and coated with a special treatment for the continuous conveyance and recycling of Flux material.  Flux Belts supplied by Upson Maybach are made right in our shop in Batavia, NY!
